24V 100Ah 200Ah Deep Cycle Lithium LiFePO4 Battery
Model:EM-24V/100AH/200AH
Voltage(V):25.6
Capacity(Ah):100/200
Size (L*W*H)(mm):490 x 171 x 240
Weight(kg):19.48
Product Introduction
The 24V 100Ah 200Ah LiFePO4 battery is an efficient and DYNAMIC power source for RVs, forklifts, and solar power systems. Its advanced design provides reliable energy storage and simplified integration.
High Efficiency
Consistent energy output for optimized performance.
Smart Protection
Integrated BMS for over-voltage, temperature, and short-circuit protection.
Durable and Lightweight
DYNAMIC design for easy installation and portability.
Sustainable Solution
Free of hazardous materials and designed for long-term use.
Technical Data
If you have any questions during the browsing process, please feel free to contact us and communicate with us at any time.
| Nominal Voltage | 25.6V |
| Nominal Capacity | 100Ah/200Ah |
| Battery Pack Energy | 2560Wh/5120Wh |
| Chemistry | LiFePO4 |
| Working Voltage | 21-29.2V |
| Charging Voltage | 28.8V |
| Max. Charging Current | 50A |
| Max. Discharge Current | 100A |
| Charging Temperature | 0-45℃ |
| Discharge Temperature | -20-45℃ |
| Storage Temperature | -20-45℃ |
| Design Life | 10years (25℃/77℉) |
| Cycle Life | ＞5000 times (25℃/80%DOD) |
| Altitude | ＜2000m |
| Weight | 19.48kg |
| Self-Consumption Power | ＜3%，Every Month |
| Output Terminal | M8 threaded hole |
| LCD | Available |
| Communication | Available |
| Dimensions | 490 x 171 x 240 mm |
