12V 150Ah 200Ah Deep Cycle Lithium LiFePO4 Battery

Model:EM-12V/150AH/200AH

Voltage(V):12.8

Capacity(Ah):150/200

Size (L*W*H)(mm):330 x 173 x 216

Weight(kg):17.5


Product Introduction


The 12V 150Ah 200Ah LiFePO4 battery delivers powerful and reliable energy storage for demanding applications such as electric wheelchairs, golf carts, and small RVs. Its advanced design ensures long-lasting performance with minimal maintenance.



High Capacity and Longevity


Delivers over 5000 cycles at 80% DOD, offering an extended lifespan compared to traditional batteries.


12V 150Ah 200Ah Deep Cycle Lithium LiFePO4 Battery 4.jpg



Enhanced Safety


Built-in BMS ensures protection against overcharge, over-discharge, and short circuits.


12V 150Ah 200Ah Deep Cycle Lithium LiFePO4 Battery 1.jpg



Robust Durability


Withstands shocks and vibrations, making it suitable for mobile environments.


12V 150Ah 200Ah Deep Cycle Lithium LiFePO4 Battery 5.jpg



Eco-Friendly and Maintenance-Free


Non-toxic materials and no need for regular maintenance.


12V 150Ah 200Ah Deep Cycle Lithium LiFePO4 Battery 6.jpg



Technical Data


If you have any questions during the browsing process, please feel free to contact us and communicate with us at any time.


Nominal Voltage12.8V
Nominal Capacity150Ah/200Ah
Battery Pack Energy1920Wh/2560Wh
ChemistryLiFePO4
Working Voltage10-14.4V
Charging Voltage14.4V
Max. Charging Current100A
Max. Discharge Current100A
Charging Temperature0-45℃
Discharge Temperature-20-45℃
Storage Temperature-20-45℃
Design Life10years (25℃/77℉)
Cycle Life>5000 times (25℃/80%DOD)
Altitude <2000m
Weight17.5kg
Self-Consumption Power<3%,Every Month
Output TerminalM8 threaded hole
LCDAvailable
Communication Available
Dimensions 330 x 173 x 216 mm
